Xiuyu Zhang, Ruijing Jing, Zhiwei Li, Zhi Li, Xinkai Chen and Chun-Yi Su, "Adaptive Pseudo Inverse Control for a Class of Nonlinear Asymmetric and Saturated Nonlinear Hysteretic Systems," IEEE/CAA J. Autom. Sinica, vol. 8, no. 4, pp. 916-928, Apr. 2021. doi: 10.1109/JAS.2020.1003435
Citation: Xiuyu Zhang, Ruijing Jing, Zhiwei Li, Zhi Li, Xinkai Chen and Chun-Yi Su, "Adaptive Pseudo Inverse Control for a Class of Nonlinear Asymmetric and Saturated Nonlinear Hysteretic Systems," IEEE/CAA J. Autom. Sinica, vol. 8, no. 4, pp. 916-928, Apr. 2021. doi: 10.1109/JAS.2020.1003435

Adaptive Pseudo Inverse Control for a Class of Nonlinear Asymmetric and Saturated Nonlinear Hysteretic Systems

doi: 10.1109/JAS.2020.1003435
Funds:  This work was supported in part by the National Natural Science Foundation of China (61673101, 61973131, 61733006, U1813201), the Japan Society for the Promotion of Science (C-18K04212), the Science and Technology Project of Jilin Province (20180201009SF, 20170414011GH, 20180201004SF, 20180101069JC), the Fundamental Research Funds for the Central Universities (N2008002), and “Xing Liao Ying Cai” Program (XLYC1907073)
More Information
  • This paper aims at eliminating the asymmetric and saturated hysteresis nonlinearities by designing hysteresis pseudo inverse compensator and robust adaptive dynamic surface control (DSC) scheme. The “pseudo inverse” means that an on-line calculation mechanism of approximate control signal is developed by applying a searching method to the designed temporary control signal where the true control signal is included. The main contributions are summarized as: 1) to our best knowledge, it is the first time to compensate the asymmetric and saturated hysteresis by using hysteresis pseudo inverse compensator because the construction of the true saturated-type hysteresis inverse model is very difficult; 2) by designing the saturated-type hysteresis pseudo inverse compensator, the construction of true explicit hysteresis inverse and the identifications of its corresponding unknown parameters are not required when dealing with the saturated-type hysteresis; 3) by combining DSC technique with the tracking error transformed function, the “explosion of complexity” problem in backstepping method is overcome and the prespecified tracking performance is achieved. Analysis of stability and experimental results on the hardware-in-loop platform illustrate the effectiveness of the proposed adaptive pseudo inverse control scheme.
